What is Quartz and its Common Use?
Quartz Material Properties
Quartz can be manufactured into Quartz Glass, which is sometimes referred to as fused quartz or fused silica. The material is composed of silicon dioxide (SiO2), which has very low thermal expansion and can maintain its dimensional stability even at elevated temperatures.
Quartz glass has excellent electrical insulation property and is inert to attacks from all kinds of acids, even in very high concentrations, except for hydrofluoric acid. The material has high compressive strength, but also displays high hardness and brittleness. Defects on the surface may have a serious impact on its overall material strength.
Common Applications of Quartz
Since quartz glass has a wide transparency range and superior light transmittance, this makes it an ideal material for multiple optical applications in optoelectronics industry, such as prisms, lenses, etc. Its material properties also gives it a wide range of applications in semiconductor industry, such as quartz ring, quartz crucible, quartz wafer boat, etc.
F1. silicon wafers in plastic wafer boat (quartz wafer boat is also applicable)
How Quartz Machining Works?
Quartz Machining 1 : Milling
F2. industrial material machining milling process
Quartz Machining 2 : Cutting
F3. industrial material cutting with high pressure water jet
Quartz Machining 3 : Drilling
F4. industrial material drilling on milling machine
Difficulties in Quartz Machining
Quartz Machining Challenges in Quality
Though quartz glass possesses high compressive strength, it is still a very hard and brittle material. Even small defects on the surface may have serious impact on its overall material strength. Especially in quartz glass drilling, there will easily be serious subsurface damage with improper cutting force. Another downside of machining quartz glass is that machining it produces great deal of powder and clogs the diamond cutting tools. This not only affects the stability of tool life, but also severely damages the quality of the workpiece.
Quartz Machining Challenges in Efficiency
Though quartz glass is considered to have relatively good machinability, it is a hard and brittle material. The control of cutting force is important when machining quartz glass, since it may be easily chipped or cracked under excessive cutting force. This usually results in a very time-consuming machining process, and leaves the processing manufacturers a huge headache when dealing with this material.
F5. the challenge of enhancing machining efficiency while maintaining required quality
What Does HIT Ultrasonic Machining Bring to Quartz Machining?
HIT’s ultrasonic-assisted machining technology provides the superimposition of the tool rotation with a high-frequency oscillation in longitudinal direction, generating over 20,000 times of micro-vibration per second. The mechanism helps reduce cutting forces and facilitates chip removal process.
F6. HIT’s ultrasonic machining technology with high-frequency oscillation in longitudinal direction facilitates chip removal process
The reduction in cutting forces not only decreases frictions between tools and workpieces, but also allows feed rates to be increased. This greatly improves the quality of workpieces and the stability of tool life, and saves quite an amount of processing time.
F7. HIT’s ultrasonic machining technology helps reduction in cutting force, bringing more stability in tool life
Facilitating chip removal process diminishes frictions on both tools and workpieces caused by excessive amount of chips. HIT’s ultrasonic high-frequency micro-vibration allows chips to break easily and lessens the occurrences of entangled chips. This also displays a great benefit to both the quality of workpieces and the stability of tool life.
The technology specializes in micro-drilling and deep hole drilling hard and brittle advanced materials, including technical ceramics, quartz glass, super alloys, etc. The high-frequency micro-vibration displays the ability to control the cutting force in stable manner, decreasing the possibilities of severe subsurface damage. Offering a better way to improve the machining process by effectively enhancing machining efficiency, stabilizing the tool life, and bettering the quality of workpieces.
F8. HIT’s ultrasonic machining technology displays outstanding results on quartz micro-drilling and deep hole drilling
More information on HIT Ultrasonic Machining Technology
Two Successful HIT Cases of Quartz Machining
Quartz Machining Case 1 : Micro-Drilling
F9. Quartz glass micro-drilling workpiece
HIT conducted a Φ0.3×5.4mm micro-drilling on a 60x30x20mm quartz glass workpiece. Using HIT’s ultrasonic tool holder HSKE40 with the integration of CTS, ATC, and CNC automation system, HIT managed to drill 300 micro-holes in total, with the processing time within 40 seconds/per hole. The outcome, in terms of machining efficiency, prevailed over the machining results provided by the tool suppliers and clients. The precision repeatability is well-maintained with no obvious edge-cracks on the hole wall.
F10. Quartz glass micro-drilling process
This feature is widely applied in the Semiconductor industry, especially being used for quartz plates, quartz rings, quartz substrate lens board, etc.
More information on Quartz : Micro-drilling
Quartz Machining Case 2 : Deep Hole Drilling
F11. Quartz glass deep hole drilling workpiece
HIT carried out a Φ3x65mm deep hole drilling on a 100x100x30mm quartz glass workpiece. Using HIT’s ultrasonic tool holder HSKA63 with the integration of CTS, ATC, and CNC automation system, HIT completed the machining process by enhancing the material removal rate (MRR) from 65.54 mm3/min (non-ultrasonic) to 533.64 mm3/min (HIT ultrasonic). This helps reduce the overall processing time over 85%, from 26 minutes 44 seconds to 3 minutes 17 seconds.
F12. Quartz drilling process
This feature is widely applied in the Optoelectronics industry and Defense and Aerospace industry, especially being used for quartz lens, quartz reflector lens, quartz lens for gyroscope etc.
More information on Quartz : Deep hole drilling
Quartz Machining FAQ
Q1 When machining quartz glass, it often produces great deal of powder. The accumulated powder may severely clog the diamond cutting tool and have a serious impact on both the tool life and the quality of workpieces. How does HIT’s ultrasonic technology deal with this situation?
A1 HIT’s ultrasonic-assisted machining technology provides the superimposition of the tool rotation with a high-frequency oscillation in longitudinal direction, generating over 20,000 times of micro-vibration per second. The mechanism helps reduce cutting forces and facilitates chip removal process. HIT’s ultrasonic high-frequency micro-vibration allows chips to break easily and lessens the occurrences of entangled chips. With the assistance of high pressure (70bar) coolant through spindle (CTS), it allows the chip removal process even smoother.
F13. HIT ultrasonic machining driver module
More information on HIT Ultrasonic Machining Module
Q2 How to adjust feed rates and amplitude when I start machining Quartz with HIT’s ultrasonic machining module system?
A2 HIT aims to help clients face the challenges in Quartz machining. This includes providing the optimum machining parameters and services to ensure clients having the best experiences in using HIT’s ultrasonic machining module system. It is not just buying a product from HIT, but obtaining the knowledge, services, and efforts from the most professional team.
F14. HIT ultrasonic tool holders
Quartz Machining? Choose HIT
Contact us if you are looking for a better way to improve machining efficiency, quality, and tool life.
